The LB10 9.6V 3.6Ah battery is listed for emergency-lighting projects. Review driver, charger, installation and model documents before selecting a sample. The short parameters and detailed table show different temperature ranges; confirm the current specification before use.
The LB10 is listed as a 9.6V 3.6Ah rechargeable battery for emergency-lighting projects. Its current product table describes a PVC pack with an XT60H-F connector and 14AWG wiring. Review the electrical interface and installation drawing before choosing a sample; a matching nominal voltage alone does not establish compatibility.
Verify protection functions and thresholds using the specification for the selected configuration. Do not infer system approval, universal replacement suitability or emergency runtime from the battery description.
The original table below is retained for initial review. The short parameters and this table currently list different charging and discharge temperature ranges. Request the current LB10 specification to resolve those differences before integration.
Also confirm the duty conditions for the row labelled maximum continuous discharge, which includes a time-limited entry. Charging-current labels need their applicable conditions; a maximum value is not automatically a recommended charging setting.
| Specification | Details |
|---|---|
| Product Type | Rechargeable Emergency Light Battery |
| Nominal Voltage | 9.6V |
| Rated Capacity | 3.6Ah at C5 |
| Minimum Capacity | 3.45Ah at C5 |
| Energy | Approximately 34Wh |
| Combination Mode | 26FC-3S1P |
| AC Internal Resistance | ≤110mΩ |
| Dimensions | 90 ± 2 × 75 ± 2 × 35 ± 1 mm |
| Product Weight | 330 ± 30g |
| Package | PVC |
| Charge Voltage | 10.8 ± 0.15V |
| Recommended Charging Current | 0.72A |
| Maximum Charging Current | 1.5A |
| Cut-Off Charging Current | 36mA–72mA |
| Standard Discharge Current | ≤3.6A |
| Maximum Continuous Discharge Current | 3.6A–10.8A for up to 5 minutes |
| End-of-Discharge Voltage | Approximately 7.5V |
| Connector | XT60H-F plug wire |
| Wire Specification | 14AWG |
| Polarity | Red positive (+), black negative (-) |
| Wire Length | 80 ± 10mm |
| Charging Temperature | 0°C to 50°C |
| Discharge Temperature | -20°C to 60°C |
Test the proposed sample with the actual charger and luminaire. Record charging behavior, loaded voltage, backup duration, temperature and cutoff behavior under representative conditions. Check mechanical fit and wiring before approving the sample.
Agree the specification revision and any required protection tests with the engineering team. The listed energy and capacity do not by themselves establish the emergency operating time of a complete lighting system.
Send the luminaire or driver specification, required runtime, charging method, installation drawing, connector details, destination market, sample quantity and expected annual demand. Identify any differences from the current pack so customization feasibility can be reviewed.
Request model-specific documentation and confirm its coverage for the final configuration and intended market. Certification marks in an image are not a substitute for applicable reports and documents.
Request an LB10 emergency lighting battery review
Browse lighting battery packs to compare listed configurations. Compare voltage, charging conditions, load limits and installation fit rather than treating similar capacity labels as interchangeable.
