36V 75Ah LiFePO4 Golf Cart Battery
The GLF05 is a 36V 75Ah LiFePO4 golf cart battery designed to replace compatible lead-acid battery systems. It delivers reliable power and a typical driving range of 60–70 miles (97–113 km) per full charge, making it ideal for golf courses, resorts, communities, and commercial golf cart fleets. Its integrated BMS helps protect against over-temperature, over-voltage, over-discharge, and short circuits, while the IP67-rated enclosure supports dependable outdoor operation. With a 10-year design life and 5-year warranty, GLF05 eliminates water refilling, acid cleanup, and routine terminal maintenance.
The Surlon Power GLF05 is a 36V 75Ah LiFePO4 golf cart battery designed to replace compatible lead-acid battery systems. With 2.88kWh of stored energy, a durable steel enclosure, and IP67-rated protection, it delivers reliable, maintenance-free power for golf courses, resorts, residential communities, and commercial golf cart fleets.
An integrated Battery Management System (BMS) helps protect against overcharge, over-discharge, over-temperature, over-voltage, and short circuits. Compared with traditional lead-acid batteries, the GLF05 eliminates water refilling, acid-deposit cleaning, and routine terminal maintenance.
High-Capacity Golf Cart Power: 75Ah capacity and 2.88kWh energy for compatible 36V systems.
Extended Driving Range: Typical range of 60–70 miles (97–113 km) per full charge, depending on vehicle load, terrain, speed, and temperature.
High-Current Performance: Supports 75A continuous discharge and up to 150A maximum discharge.
Integrated BMS Protection: Helps support safe and stable operation in daily fleet use.
IP67-Rated Steel Enclosure: Provides strong protection against dust and temporary water immersion.
Low-Maintenance Operation: No watering, acid cleanup, or routine terminal servicing.
Long-Term Value: Up to 5,000 cycles, a 10-year design life, and a 5-year warranty under specified operating conditions.
Compatible System Integration: Designed for compatible 36V golf cart platforms; confirm fitment before installation.
The GLF05 lithium golf cart battery is suitable for compatible applications including:
Golf carts and golf-course fleets
Resort and hotel transportation
Residential community vehicles
Campus and facility mobility carts
Low-speed electric vehicles
Custom 36V electric mobility projects
| Category | Specification | Details |
|---|---|---|
| Model | Product Model | GLF05 |
| Electrical | System Voltage | 36V |
| Electrical | Nominal Voltage | 38.4V |
| Electrical | Nominal Capacity | 75Ah |
| Electrical | Stored Energy | 2.88kWh |
| Electrical | Continuous Charge Current | 35A |
| Electrical | Continuous Discharge Current | 75A |
| Electrical | Maximum Charge Current | 40A |
| Electrical | Maximum Discharge Current | 150A |
| Performance | Typical Range per Full Charge | 60–70 miles (97–113 km) |
| Mechanical | Dimensions (L × W × H) | 16.93 × 15.12 × 8.07 in. / 430 × 384 × 205 mm |
| Mechanical | Weight Without Counterweight | 63 ±5 lbs. / 29 ±2.5 kg |
| Mechanical | Casing Material | Steel |
| Protection | IP Rating | IP67 |
| Environmental | Charge Temperature | 32°F to 131°F / 0°C to 55°C |
| Environmental | Discharge Temperature | -4°F to 131°F / -20°C to 55°C |
| Environmental | Storage Temperature, up to 1 Month | -4°F to 113°F / -20°C to 45°C |
| Environmental | Storage Temperature, up to 1 Year | 32°F to 95°F / 0°C to 35°C |
Compared with conventional lead-acid batteries, LiFePO4 batteries offer longer cycle life, stable voltage output, lower maintenance requirements, and improved operating efficiency. The GLF05 helps operators reduce battery servicing time and keep golf cart fleets available for daily operation.
Before purchase, confirm battery compartment dimensions, system voltage, charger compatibility, cable connections, controller requirements, and vehicle balance requirements.
The GLF05 is designed for compatible 36V golf cart systems. Check the battery compartment dimensions, mounting arrangement, charger profile, connectors, controller requirements, and vehicle balance before purchase.
Typical range is 60–70 miles (97–113 km) per full charge. Actual range varies with vehicle model, passenger and cargo load, terrain, tire condition, speed, and ambient temperature.
No water refilling or acid-deposit cleaning is required. Periodically inspect cables, terminals, mounting hardware, and charging equipment.
The battery is IP67-rated, providing protection against dust and temporary water immersion. It should not be exposed to prolonged submersion or conditions beyond its rated protection level.
The integrated BMS helps protect against overcharge, over-discharge, over-temperature, over-voltage, and short circuits.
OEM and ODM options may be available for qualified projects, including customized dimensions, connectors, labels, and other application-specific requirements.
Contact Surlon Power for compatibility guidance, technical support, customization options, and a quotation for the GLF05 36V 75Ah LiFePO4 golf cart battery.
